Dell PERC H755 Обзор
The Dell PERC H755 is a high-performance RAID controller designed to enhance the storage capabilities of Dell PowerEdge servers. It offers advanced data protection and management features, ensuring optimal performance and reliability for enterprise applications. The controller supports various RAID levels, providing flexibility and redundancy in data storage, making it an ideal choice for businesses looking to improve their server storage infrastructure.
Quick Spec
Model | Dell PERC H755 |
RAID Levels | 0, 1, 5, 6, 10, 50, 60 |
Interface | PCIe Gen 4 |
Cache Memory | 8GB DDR4 |
Maximum Drives | up to 32 |
Product Features
- Advanced RAID management
- Support for up to 32 drives
- 8GB DDR4 cache memory
- PCIe Gen 4 interface
- Comprehensive data protection
Product Applications
- Enterprise data storage solutions
- High-availability server environments
- Data-intensive applications requiring high-speed RAID controllers
Supported Options
Accessory | Model |
Battery Backup Unit | Dell BBU05 |
CacheCade Pro 2.0 | Dell CacheCade Pro 2.0 |
SuperCap Power Module | Dell SCPM01 |
Compare to Similar Items
Model | Difference |
Dell PERC H740P | PCIe Gen 3, 4GB Cache |
Dell PERC H730 | PCIe Gen 3, 1GB Cache |
Dell PERC H745 | PCIe Gen 4, 4GB Cache |
Get more information
For further information about the Dell PERC H755 RAID controller and its pricing, please contact us through Live Chat or at genius@firstlan.ru. Check Dell PERC H755 price and PERC H755 datasheet, buy Dell PERC H755 RAID controller with the best price and fast shipping. Free Live Chat support is also available.
Dell PERC H755 Спецификация
Dell PERC H755 Specifications | |
Brand | Dell |
Model | PERC H755 |
Type | RAID Controller |
Form Factor | Low Profile |
Interface | PCIe 4.0 x8 |
Supported RAID Levels | 0, 1, 5, 6, 10, 50, 60 |
Cache Memory | 8GB DDR4 |
Controller Processor | Multi-core RAID-on-Chip (ROC) |
Supported Devices | SAS, SATA HDDs and SSDs |
Max Number of Devices | Up to 240 SAS/SATA devices |
Max Cache Memory Backup | 12 hours via battery |
Operating Temperature | 0°C to 55°C |
Relative Humidity | 20% to 80% (non-condensing) |
MTBF | Over 2 million hours |
Dimensions | 2.713 x 6.6 x 0.625 inches |
Power Consumption | 17W |
Battery Life | Up to 5 years |
RAID Management | Dell OpenManage Storage Services |
Encryption | Self-Encrypting Drives (SED) support |
Data Transfer Rates | 12Gb/s SAS, 6Gb/s SATA |
