NVIDIA Mellanox MCX75310AAS-NEAT Обзор
The Mellanox MCX75310AAS-NEAT, a high-caliber NVIDIA ConnectX-7 HHHL (Half-Height, Half-Length) Adapter Card, is engineered to redefine the boundaries of network performance. This single-port OSFP card supports 400GbE / NDR InfiniBand in its default mode, delivering unparalleled networking speeds for advanced data centers and high-performance computing environments. Utilizing a PCIe 5.0 x16 interface, it maximizes bandwidth and minimizes latency, setting a new standard for data transfer efficiency. With Crypto Disabled and Secure Boot Enabled, it offers a secure networking solution, prioritizing the integrity of data and system safety. The inclusion of a tall bracket enhances its compatibility with a wide array of server setups, making it a versatile choice for enterprises aiming to upgrade their network infrastructure to the cutting edge.
QuickSpec
| Brand | Mellanox |
| Model | MCX75310AAS-NEAT |
| Interface | PCIe 5.0 x16 |
| Ports | Single-port OSFP |
| Network Speed | 400GbE / NDR InfiniBand |
| Features | Crypto Disabled, Secure Boot Enabled |
| Form Factor | HHHL with Tall Bracket |
Product Features
- Single-port OSFP interface offering unprecedented flexibility and speed for Ethernet and InfiniBand networks.
- PCIe 5.0 x16 interface ensures the highest level of bandwidth and the lowest latency, enhancing overall system performance.
- Designed with security in mind: features such as Crypto Disabled and Secure Boot Enabled for safe and reliable computing environments.
- Accommodates various server configurations with the inclusion of a tall bracket, simplifying the installation process.
- Optimized for demanding applications in high-performance computing, cloud, storage, and network transport.
Product Applications
- Advanced Data Centers: Ideal for next-generation networks requiring ultra-high-speed interconnects and enhanced security.
- High-Performance Computing (HPC): Suitable for research and simulation tasks that demand rapid data processing and transport.
- Cloud Infrastructure: Supports the backbone of cloud service providers with robust, secure, and high-bandwidth networking capabilities.
Supported Options
| Networking Cables | Premium OSFP cables for 400GbE / NDR connectivity |
| Network Management Software | Compatible with NVIDIA Cumulus and NVIDIA Onyx for advanced network management |
| Bracket Options | Comes standard with a tall bracket, with low-profile options available for diverse installation needs |
Compare to Similar Items
| Model | MCX75310AAS-NEAT | MCX75310AAC-NEAT | MCX75510AAS-NEAT | MCX715105AS-WEAT |
|---|---|---|---|---|
| Ports | Single-Port OSFP | Single-Port OSFP | Single-Port OSFP | Single-Port QSFP112 |
| PCIe Interface | PCIe 5.0x 16 | PCIe 5.0x 16 | PCIe 5.0x 16 | PCIe 5.0x 16 |
| Support InfiniBand Data Rate | NDR/NDR200/HDR/HDR100/EDR/FDR/SDR | NDR/NDR200/HDR/HDR100/EDR/FDR/SDR | SDR/FDR/EDR/HDR/NDR/NDR200 | NDR/NDR200/HDR/HDR100/EDR/FDR/SDR |
| Support Ethernet Data Rate | 400/200/100/50/40/10/1 Gb/s | 400/200/100/50/40/10/1 Gb/s | — | 400/200/100/50/25/10 Gb/s |
| RDMA |  | | | |
| ASAP2 (Virtual Switch offload) | | | | |
| SR-IOV | | | | |
| Hardware-based I/O Virtualization | | | | |
Get more information
For more details about the Mellanox MCX75310AAS-NEAT NVIDIA ConnectX-7 HHHL Adapter Card and how it can transform your networking setup, please don't hesitate to contact us through Live Chat or via email at genius@firstlan.ru. Our expert team is ready to offer comprehensive support and assist you in finding the best networking solutions for your specific requirements.
