Характеристики

Модель : NCS-5516

Детали : NCS5500 16 Slot Configured Chassis

Информация на сайте Firstlan.ru, включая цены и характеристики, представлена для справки и не является публичной офертой, определяемой положениями Статьи 437 Гражданского кодекса РФ. Договор заключается только после предварительного согласования наличия, наименования и количества товара.

Путь от задачи до результата

За 4 шага

Обзор

NCS-5516 Обзор

Cisco NCS-5516 Product Introduction

The Cisco NCS-5516 is a high-performance 16-slot configured chassis designed for large-scale networks. Ideal for service providers and enterprises, it delivers enhanced scalability, robust performance, and network reliability in diverse data environments.

Cisco NCS-5516 Product Highlights

High-density 16 slots
Advanced scalability
Enhanced network reliability
High-performance throughput
Carrier-grade hardware

Cisco NCS-5516 Product Features Comparison

Model	Slot Capacity	Line Card Support	Redundancy	Throughput	Power Efficiency	Form Factor	Operational Temperature Range
Cisco NCS-5516	16 slots	Yes	Yes	High	Efficient	Rack-mount	0 to 40??C
Cisco NCS-5508	8 slots	Yes	Yes	Moderate	Efficient	Rack-mount	0 to 40??C
Cisco ASR 9904	4 slots	Yes	Yes	Moderate	Efficient	Rack-mount	0 to 45??C
Huawei NE40E-X8A	8 slots	Yes	Yes	High	Efficient	Rack-mount	0 to 40??C
Juniper MX480	6 slots	Yes	Yes	High	Efficient	Rack-mount	0 to 40??C
Alcatel-Lucent 7750	4 slots	Yes	Yes	Moderate	Efficient	Rack-mount	-5 to 45??C

Cisco NCS-5516 Product Application Scenarios

Service provider edge routing
Data center interconnects
High-capacity backbone networks

Optional Add-ons

Model	Description
NCS-5500-FAN	Cooling Fan Tray
NCS-5500-PSU	Power Supply Unit
NCS-5500-ETH	Ethernet Line Card

Get More Information

Discover unbeatable prices and fast shipping for the Cisco NCS-5516. Access the detailed NCS-5516 datasheet and ensure you're getting the best deal with our reliable delivery service. Need assistance? Our free live chat support is here to help. For more information about the product and pricing, contact us via live chat or email us at genius@firstlan.ru.

Сертификаты качества

Спецификация

NCS-5516 Спецификация

Cisco NCS-5516 Specifications
Product Model	NCS-5516
Chassis Type	16 Slot Configured Chassis
System Bandwidth	Up to 172.8 Tbps
Slots for Line Cards	16
Slots for Route Processors	3
Fabric Module Slots	6
Scalability	Scales to 1 million routes and 400 million addresses
Forwarding Capacity	Up to 8 billion packets per second (Bpps)
Redundancy	Supports component-level redundancy
Interface Support	100GE, 40GE, 10GE, and OTU4
Power Supply	AC and DC options available
Cooling	Front-to-back airflow
Dimensions (H x W x D)	42 RU x 19 in. x 33.5 in.
Operating Temperature	0??C to 40??C
Non-Operating Temperature	-40??C to 70??C
Operating Humidity	5% to 85% (non-condensing)
Non-Operating Humidity	5% to 95% (non-condensing)
Compliance Standards	ROHS, NEBS Level 3
MTBF	Est. 300,000 hours
Software	Cisco IOS XR
Security Features	Hardware-based encryption, control plane protection

Модель

NCS-5516

Детали

NCS5500 16 Slot Configured Chassis
